Machine Description
Rotary leak tester is composed with conveyor system, leak testing system and PLC control system. Empty bottle will enter rotary system through infeed star-wheel. Any defected bottle will be automatically rejected on machine outfeed.
-
Feature
-
Machine Parameter
Item
Parameter
Note
Electricity
3 phases 5 wires
power
2KW
Air pressure
0.6±0.1MPa
Air consumption
100L/min filteredair
Applied bottle size
Any 50ml~100ml which can stand on conveyor
Testing parameter
Accuracy hole≥0.2mm；
Accuracy >99.9%；
Error rate<0.1%
Testing channel
24
related to bottle size, channel
Max Speed
420BPM
Machine size
2000（L）X1000(W)X1700（H）
Weight
Approx. 600KG
EPDR Rotatry Leak Tester
Rotary leak tester is composed with conveyor system, leak testing system and PLC control system. Empty bottle will enter rotary system through infeed star-wheel. Any defected bottle will be automatica
